I have seen similar things for disk reports from Windows machines. I setup a cronjob to clean up the ones over a day old like this:

Delete RRD disk,ProgramData (Windows 10/11 Portable Base Layer sandbox

partition) over a day old, as name changes with reboots 0 0 * * * find /home/xymon/data/rrd/* -name disk,ProgramData\* -mtime +1 -exec /bin/rm -f '{}' \;

You could do a similar cronjob for your veeam snapshots.

Tom

On Tue, Feb 18, 2025 at 7:43 AM Neil Simmonds via Xymon <xymon@xymon.com> wrote:

It appears I have answered my own question

In the /var/lib/Xymon/rrd directory (I’m using Terabithia RPM version of Xymon) there were a large number of files with names similar to

disk,tmp,veeam,{f8dc516e-d17d-4a7e-b473-fd40e2d1a531}.rrd

these, as far as I can tell are veeam snapshots that are obviously being seen by the disk check and rrd file created but when there’s too many it crashed the trends column.

There were only two servers that had these excess files. I have now deleted them and all is working again.

Neil Simmonds

Senior Platform & Middleware Engineer (Unix) [image: fgfs.jpg]

PHONE

0344 245 9200

ADDRESS

Unit A Brook Park East, NG20 8RY

Credit is provided by Frasers Group Financial Services Limited (Registered Company no. 00718151), which is authorised and regulated by the Financial Conduct Authority (FRN 311908) for consumer credit and general insurance and a member of the Finance and Leasing Association. Frasers Group Financial Services Limited is registered in England and its registered office is: Express House, Petre Road, Clayton Business Park, Accrington, Lancashire, BB5 5JB. Studio is a trading name used by both Frasers Group Financial Services Limited and Studio Retail Trading Limited. For regulated payment services, Frasers Group Financial Services Limited is a payment agent of Transact Payments Limited, a company authorised and regulated by the Gibraltar Financial Services Commission as an electronic money institution. Transact Payments Limited, a company incorporated in Gibraltar (No 108217). Registered address 6.20 World Trade Center, 6 Bayside Road, Gibraltar, GX11 1AA. Disclaimer | Frasers Group <https://frasers.group/legal/disclaimer>

*From:* Neil Simmonds via Xymon <xymon@xymon.com> *Sent:* 18 February 2025 14:05 *To:* xymon@xymon.com *Cc:* Neil Simmonds <Neil.Simmonds@frasers.group> *Subject:* [Xymon] Weird issue with Trands on a small amount of servers

Hi all,

On a couple of servers (maybe more) I get the following when trying to access the “trends” column

*Internal Server Error*

The server encountered an internal error or misconfiguration and was unable to complete your request.

Please contact the server administrator at root@localhost to inform them of the time this error occurred, and the actions you performed just before this error.

More information about this error may be available in the server error log.

When I look in messages.log on the server I can see this

Feb 18 13:04:25 XymonServer kernel: svcstatus.cgi[3993679]: segfault at 1fe5965 ip 00007faddb3f79ad sp 00007ffd48ba9c60 error 6 in libc-2.28.so [7faddb369000+1cd000]

Feb 18 13:04:25 XymonServer kernel: Code: ba ff ff ff ff be 00 80 00 00 e8 8e 53 00 00 48 89 df 48 89 e9 4c 89 e2 48 8d 05 fe e6 33 00 48 89 ee 48 89 84 24 d8 00 00 00 <c6> 45 00 00 e8 3a 68 00 00 48 89 df 4c 89 f2 4c 89 ee e8 6c 7a fd

Feb 18 13:04:25 XymonServer systemd[1]: Started Process Core Dump (PID 3993684/UID 0).

Feb 18 13:04:25 XymonServer systemd-coredump[3993685]: Resource limits disable core dumping for process 3993679 (svcstatus.cgi).

Feb 18 13:04:25 XymonServer systemd-coredump[3993685]: Process 3993679 (svcstatus.cgi) of user 48 dumped core.

Feb 18 13:04:25 XymonServer systemd[1]: systemd-coredump@109-3993684-0.service: Succeeded.

I’m unable to find an actual core dump file to help any further so am struggling to diagnose this one. Can anyone help?

Kind regards,

Neil.

• Neil Simmonds*

Senior Platform & Middleware Engineer (Unix)

[image: fgfs.jpg]

*PHONE *

0344 245 9200

*ADDRESS *

Unit A Brook Park East, NG20 8RY
